Surtace Mounted Edge Lit Panel Light

You are welcomed to come to our factory to buy the latest selling, newest, cheap, fashion and high quality Surtace Mounted Edge Lit Panel Light. You can rest assured to buy discount product from us. We look forward to cooperating with you, if you want to know more, you can consult us now, we will reply to you in time!

Send Inquiry

Product Description

Surtace Mounted Edge Lit Panel Light

1. Features of Surface mounted edge lit panel light(ceiling led panel light、best quality led panel light)

Surface Mounted

Ultra Slim<0.8 Inch(20mm)

LM80 Lamp Source

Driver build in, PF>0.9

Dimmable, Noise<20dB

Easy Install, Only One Person Required

Compliant with UL, ETL, ES

2. Parameters of Surface mounted edge lit panel light

Item Model ODSEPL1*4-40W-D-NA
LED chip 4014 EVERLIGHT
Size L1213*W300*H20mm
WATTS 40W
Voltage 120V
PF 0.9
Ra 80
CCT 4000K
Efficiency 100Lm/w
Warranty 2 years

3. Description of Surface mounted edge lit panel light

LED Panel Light Series ODEER patent design, dimming with light switch or dimming driver.

Comparable quality of light with halogen lighting ,High color rendering index of Ra 80

Uniform color temperature (+/- 100K), Color temperatures of 4000K

High average life of 50,000 hours

Immediate Start with 100% initial brightness. Mercury-free.

4. LED Panel Light Advantages of Surface mounted edge lit panel light

Unlike traditional troffers that can be very bulky, LED panels have an incredibly thin design, making them ideal for applications with shallow ceilings. They only weigh about seven pounds each making them lightweight enough to allow for one-man installation, reducing labor costs whether retrofitting an office or installing panels in new construction.

5. Application of Surface mounted edge lit panel light

Once the integrated LED driver has been properly wired, tabs on the back of the fixture must be bent for the panel light to hang directly from the drop ceiling. Some of our LED panels also have the option of being suspension mounted with the right mounting hardware for greater versatility.

Hot Tags: Surtace Mounted Edge Lit Panel Light, China, Manufacturers, Factory, Wholesale, UL, ETL, DLC, Energy Star, CE, TUV, SAA, Customized, High Quality, Newest, Latest Selling
